Cable Products
Katam Private Limited offers a comprehensive range of electrical wires and power cables designed for reliable performance across residential, industrial, infrastructure and power applications. Our cable portfolio includes house wires, flexible cables, LT and HT power cables, control cables, solar cables, instrumentation cables, armoured cables and submersible cables, with specifications defined according to the intended application and applicable industry standards.
House Wires
Annealed Copper
Solid / Stranded
Class 1 / Class 2
PVC
450/750 V
0.5–16 mm²
Up to 70°C
Single Core
FR / FR-LSH options
IS 694 / IEC 60227
Coils / Boxes / Reels
Residential wiring, commercial buildings, offices, lighting and general electrical installations
Flexible Cables
Annealed Copper
Flexible Stranded
Class 5 / Class 6
PVC / Elastomer
Up to 450/750 V
0.5–240 mm²
1–5 Cores
Up to 70°C / as per insulation
PVC / Elastomer
IEC 60227 / applicable IS standards
Coils / Reels / Drums
Control panels, machinery, portable equipment, industrial connections and flexible electrical installations
LOW TENSION Power Cables​
Copper
Stranded / Compacted
Class 2
XLPE / PVC
1.1 kV
1 / 2 / 3 / 3.5 / 4 Core
1.5–630 mm²
PVC / appropriate compound
PVC / LSZH options
Optional
XLPE: up to 90°C
IS 7098 / IS 1554 / IEC 60502-1 as applicable
Drums / Reels
Power distribution, industrial plants, commercial buildings, infrastructure and utilities
HIGH TENSION Power Cables​
Copper
Stranded / Compacted
Class 2
XLPE
3.3 kV–33 kV
Single / 3 Core
25–1,000 mm²
Semi-conductive
Semi-conductive
Copper Tape / Wire Screen
PVC / PE / LSZH as applicable
90°C continuous
IS 7098 / IEC 60502-2 as applicable
IS 7098 / IEC 60502-2 as applicable
Power transmission, distribution networks, substations, industrial plants and infrastructure
Control Cables
Annealed Copper
Flexible Stranded
Class 5
PVC / XLPE
300/500 V / 450/750 V / 0.6/1 kV as applicable
2–61 Cores
0.5–6 mm²
Overall / Individual Screen options
As applicable
PVC / LSZH
Up to 70°C / 90°C depending on insulation
Applicable IS / IEC standards
Drums / Reels
Industrial automation, control panels, machinery, process control and electrical systems
Solar Cables
Tinned Copper
Fine-Stranded Flexible
Class 5
Cross-Linked Compound
Cross-Linked Compound
1.5 kV DC
1.5–35 mm²
90°C continuous
120°C for limited duration
Yes
Yes
IEC 62930
Coils / Reels
Solar PV modules, solar arrays, string connections and photovoltaic power systems
Instrumentation Cables
Annealed Copper
Stranded / Flexible
0.5–2.5 mm²
PVC / XLPE
1 Pair / Multi-Pair
Individual / Overall Screen
Tinned Copper
PVC / LSZH
300/500 V
Up to 70°C / 90°C depending on insulation
Drums / Reels
Process instrumentation, industrial automation, measurement systems, control systems and signal transmission
Armoured Cables
Copper
Stranded / Compacted
Class 2
XLPE / PVC
1.1 kV / 3.3–33 kV
Single / Multi-Core
1.5–1,000 mm²
GI Steel Wire / Steel Tape
PVC / appropriate compound
PVC / PE / LSZH
Applicable IS / IEC standards
Heavy-duty Cable Drums
Underground power distribution, industrial plants, infrastructure, utilities and construction projects
Submersible Cables
Annealed Copper
Flexible Stranded
Class 5
PVC / Elastomer
450/750 V / 1.1 kV
3 / 4 Core
1.5–120 mm²
Suitable for continuous submersible service
Water-resistant PVC / Elastomer
Up to 70°C / 90°C depending on insulation
Applicable IS / IEC standards
Coils / Drums
Borewell pumps, submersible pumps, agricultural irrigation, water supply systems and industrial pumping
Standard specifications shown represent Katam's standard product range. Cable construction, conductor size, number of cores, insulation system, voltage rating and other technical parameters may vary according to the applicable standard and product configuration.
